TECHNICAL DETAILS

• 12.5V LifePo4 battery
• LED Chip Osram/Bridgelux/Seol
• LED Color Temperature 3000k/5000k/6500k
• Color Rendering Index >75
• Charge Controller Efficiency > 90%
• LED Driver Efficiency > 90%
• Duty Cycle First Six Hours 100% Brightness Rest 50%
• IP Waterproof Protection Ip66
• Three Stage Battery Monitoring Algorithm
• Short Circuit Protection
• Battery Over Charge Protection
• Battery Deep Discharge Protection
• PV Reverse Voltage Polarity Protection
• Battery Reverse Voltage Polarity Protection
• NTTV (Night Time Threshold Voltage) 4.0 Volts
• DTTV (Day Time Threshold Voltage) 6.0 Volts
• Battery Low Load Disconnect Voltage 11.2 Volts
• Battery Full Load Reconnect Voltage – 13 Volts
• Battery Constant Voltage Set Point – 14.7 Volts

LED INDICATION

• Green Off: Battery Not Charging PV Low
• Green On: Battery Charging
• Green Flashing: Battery Full
• Red Off: Battery Not Discharged
• Red On: Battery Discharged Load Disconnect
